Same Sky’s Thermal Management Group announced the addition of thermoelectric generator (TEG) modules to its product portfolio. Utilizing the temperature difference between the hot and cold of the module to generate usable power, these thermoelectric generators offer output power from 5.4 up to 21.6 W in packages from 30 x 30 mm to 56 x 56 mm with profiles as low as 3.5 mm. They are ideally used in applications where waste heat is present, like industrial processes, to recover energy that would otherwise be lost.
These TEG modules feature silicone sealing, continuous maximum hot side temperatures up to 300°C, and graphite pad options for a simplified thermal interface. The models also carry open circuit voltages from 8 to 17.7 Vdc and AC resistance from 0.25 up to 4.2 ohms measured at 27°C and 1000 Hz.
The SPG models are available immediately with prices starting at $49.55 per unit at 25 pieces through distribution. Please contact Same Sky for OEM pricing.
For helpful resources and tools on thermal management, check out Same Sky’s Resource Library which houses a range of blog posts, videos, and more.
